Radium 20-1000-0806F Low Profile Swivel Banjo Fitting, 8AN ORB to 6AN Female
Radium 20-1000-0806F Low Profile Swivel Banjo Fitting, 8AN ORB to 6AN Female
SKU: SKU: 20-1000-0806F
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
4 In Stock
Taxes included.
More info
The Radium Engineering 20-1000-0806F Low Profile Swivel Banjo Fitting has a 8AN ORB inlet and a 6AN Female outlet, giving a 90-degree, low-profile connection.
It rotates a full 360 degrees — even after installation — making it an excellent option for 90-degree connections in tight engine bays where clearance and hose routing are critical. Suitable for high pressure fuel and oil systems (do not exceed 400 psi) and safe for all fuel types, oil and engine coolant.
Key Features
- 360° swivel — rotates freely even after installation
- Low profile — 0.797in (20.2mm) installed height
- High pressure rated — do not exceed 400 psi
- Media — all fuel types (incl. E85), oil and engine coolant
Specifications
| Part Number | 20-1000-0806F |
| Inlet | 8AN ORB (O-ring boss) |
| Outlet | 6AN Female |
| Type | Low profile 360° swivel banjo |
| Installed Height | 0.797in (20.2mm) |
| Max Pressure | 400 psi |
| Media | All fuels (incl. E85), oil, engine coolant |
| Sold | Individually |
Installation Notes
- Lubricate the ORB O-ring with O-ring lube, petroleum jelly or oil before installation to prevent damage.
- AN flare connections should be installed dry and clean. Hand thread until fully engaged, then tighten 1/4 to 1/2 turn after bottoming out by hand.
Related Swivel Banjo Fittings
- 20-1000-0806 Low Profile Swivel Banjo Fitting, 8AN ORB to 6AN Male
- 20-1000-0808 Low Profile Swivel Banjo Fitting, 8AN ORB to 8AN Male
- 20-1000-0810 Low Profile Swivel Banjo Fitting, 8AN ORB to 10AN Male
- 20-1000-08313 Low Profile Swivel Banjo Fitting, 8AN ORB to 5/16" SAE Quick Connect Male
- 20-1000-08375 Low Profile Swivel Banjo Fitting, 8AN ORB to 3/8" SAE Quick Connect Male
- 20-1000-0810S Low Profile Swivel Banjo Fitting, 8AN ORB to 10mm SAE Quick Connect Male
- 20-1000-0816S Low Profile Swivel Banjo Fitting, 8AN ORB to 16mm SAE Quick Connect Male
- 20-1000-0812S Low Profile Swivel Banjo Fitting, 8AN ORB to 12mm SAE Quick Connect Male
- 20-1000-0885 Low Profile Swivel Banjo Fitting, 8AN ORB to 8.5mm Barb
- 20-1000-0810B Low Profile Swivel Banjo Fitting, 8AN ORB to 10mm Barb
See the full range: Radium Swivel Banjo Fittings
Why Radium Engineering?
- ✔ Designed and manufactured in the USA
- ✔ CNC machined, precision fit — fuel, oil and coolant safe
- ✔ Trusted by professional motorsport teams and serious enthusiasts worldwide
- ✔ Exclusively distributed in Australia by Coore
Genuine Radium Engineering product, supplied by Coore Australia. Sold individually.
