Öhlins Road & Track Coilovers – Porsche 911 991 Carrera 4 / Targa 4 / Turbo (AWD)
Öhlins Road & Track Coilovers – Porsche 911 991 Carrera 4 / Targa 4 / Turbo (AWD)
SKU: SKU: POS MU00S1
More info
Öhlins Road & Track Coilovers – Porsche 911 991 Carrera 4 / Targa 4 / Turbo (AWD)
Part Number: POS MU00S1 | Fitment: Porsche 911 991.1 & 991.2 — Carrera 4, Targa 4, Turbo variants
Over 40 years of motorsport engineering distilled into a street-ready coilover kit. The Öhlins Road & Track series delivers a genuine racing experience without sacrificing daily drivability — thanks to Öhlins' proprietary Dual Flow Valve (DFV) technology. Featuring a McPherson front strut and conventional rear shock with a 10–20mm lowering range. Springs are included with our kit. Corrosion-tested to ISO 9227 and backed by a 2-year limited warranty.
⚠️ Note: Front length adjuster (06245-04) must be ordered separately for all models.
⚠️ Note: For vehicles equipped OE with PASM (Porsche Active Suspension Management), an Öhlins cancellation kit is also required (sold separately). See cancellation kit table below.
Vehicle Fitment — Porsche 911 991.1 & 991.2 (AWD Models)
| Porsche 911 Carrera 4 | 991.1 & 991.2 |
| Porsche 911 Carrera 4S | 991.1 & 991.2 |
| Porsche 911 Carrera 4 GTS | 991.1 & 991.2 |
| Porsche 911 Carrera 4 Cabriolet | 991.1 & 991.2 |
| Porsche 911 Carrera 4S Cabriolet | 991.1 & 991.2 |
| Porsche 911 Carrera 4 GTS Cabriolet | 991.1 & 991.2 |
| Porsche 911 Targa 4 | 991.1 & 991.2 |
| Porsche 911 Targa 4S | 991.1 & 991.2 |
| Porsche 911 Targa 4 GTS | 991.1 & 991.2 |
| Porsche 911 Turbo | 991.1 & 991.2 |
| Porsche 911 Turbo S | 991.1 & 991.2 |
| Porsche 911 Turbo Cabriolet | 991.1 & 991.2 |
| Porsche 911 Turbo S Cabriolet | 991.1 & 991.2 |
Technical Specifications
| Part Number | POS MU00S1 |
| Technology | DFV — Dual Flow Valve |
| Front Damper Type | McPherson strut |
| Rear Damper Type | Conventional shock absorber |
| Damping Adjustment | Single bleed adjuster (front & rear) |
| Front Spring Rate | 70 N/mm (Part No. 48000-19) — included |
| Rear Spring Rate | 140 N/mm (Part No. 48010-47) — included |
| Lowering Range | Approx. 10–20mm below standard (front & rear) |
| Top Mounts | Use with original top mounts (front & rear) |
| Springs Included | Yes — front & rear springs included |
| Rebuildable | Yes |
| Corrosion Testing | ISO 9227 salt spray tested |
| Warranty | 2-year limited warranty |
Included Springs
| Position | Part No | Spring Rate |
|---|---|---|
| Front | 48000-19 | 70 N/mm |
| Rear | 48010-47 | 140 N/mm |
Additional Parts (ordered separately for all models)
| Part No | Description |
|---|---|
| 06245-04 | Front length adjuster — Porsche 991 (2pc per car set) — required for all models |
PASM Cancellation Kit (if required)
For vehicles equipped OE with PASM (Porsche Active Suspension Management), an Öhlins cancellation kit must also be used. Ordered separately.
| Part No | Description |
|---|---|
| 35020-07 | Cancellation kit PASM |
General Features
- DFV technology (Dual Flow Valve) — Öhlins' proprietary damping system
- Individual height adjustment — approx. 10–20mm below standard
- Single bleed adjuster — compression and rebound
- Rebuildable for custom tuning
- Corrosion salt spray tested (ISO 9227)
- 2-year limited warranty
- Front & rear springs included
Front Features
- McPherson strut
- Single bleed adjuster
- Height adjustable — approx. 10–20mm lower than standard
- Coil springs included (70 N/mm — Part No. 48000-19)
- Use with original top mounts
Rear Features
- Conventional shock absorber
- Single bleed adjuster
- Height adjustable — approx. 10–20mm lower than standard
- Coil springs included (140 N/mm — Part No. 48010-47)
- Use with original top mounts
What is DFV (Dual Flow Valve)?
DFV is Öhlins' proprietary damping technology that sets the Road & Track range apart from conventional coilovers. The dual flow valve provides consistent damping characteristics on both compression and rebound strokes — the damper fluid follows a consistent flow path in both directions. This means the wheel and tyre can rapidly return to the road surface after a bump, maximising grip and traction at all times.
Because DFV opens more quickly on minor road imperfections, ride comfort is surprisingly supple — more akin to an OEM strut than a typical coilover. Over undulating surfaces, the compliance of the R&T units allows the car to crest bumps and potholes while remaining stable and in control. Traction is always maintained at its optimum level.
Why Öhlins Road & Track?
- ✅ Over 40 years of motorsport engineering heritage — trusted by factory race teams worldwide
- ✅ DFV technology — genuine race-car response with OEM-level daily comfort
- ✅ Covers all 991.1 & 991.2 AWD variants — Carrera 4, Targa 4, Turbo & Turbo S
- ✅ Springs included — 70/140 N/mm front & rear, ready to fit
- ✅ Rebuildable, ISO 9227 corrosion-tested, 2-year limited warranty
