Flat Wire Helper Springs / Spacers
Premium 110-Series (Various IDs)
These 110mm length flat wire springs feature ultra-low rates (0.5 - 1.0 N/mm) and a minimal 20mm block height. They are designed primarily as spacers or very light helpers to ensure the main spring remains seated at full droop without influencing the spring rate during compression.
Lo Open Length (mm)
R Spring Rate (N/mm)
Di Inside Diameter (mm)
Sn Block Length (mm)
Fn Force at Block (N)
St Usable Stroke (mm)
| Part Number | Lo | R | Di | Sn | Fn | St |
|---|---|---|---|---|---|---|
| AST-110-01-55 | 110 | 1 | 55 | 20 | 90 | 90 |
| AST-110-01-61 | 110 | 1 | 61 | 20 | 90 | 90 |
| AST-110-0,5-75 | 110 | 0.5 | 75 | 20 | 45 | 90 |
