Radium 6AN ORB with 10mm Barb to 6AN Male Bulkhead

Radium 6AN ORB with 10mm Barb to 6AN Male Bulkhead

Application: Universal – 6AN ORB (9/16"-18) ports, including Radium fuel hangers
Part Type: 6AN ORB bulkhead fitting – hose barb (underside) to 6AN male flare (top)
Part Number: 14-0670

The Radium 14-0670 is an anodised aluminium 6AN ORB bulkhead fitting. It has a barbed hose connection on the underside and a 6AN male flare connection on the top side, so a hose inside the tank or hanger can be connected to standard AN plumbing outside.

The thread is 6AN ORB (O-ring boss, 9/16"-18) for use in various Radium hangers or any ORB-threaded surface. Radium lists it with its 6AN ORB to AN connections and its 6AN ORB bulkhead fittings.

Key Features

• Bulkhead Design: Barbed hose connection underneath, 6AN male flare on top
• 6AN ORB Thread: 9/16"-18 O-ring boss thread for Radium hangers or any ORB-threaded surface
• Anodised Aluminium: Anodised aluminium construction
• FKM O-Ring: Compatible with all oil and fuel types

Important Notes

• Lubricate the O-rings with engine oil, O-ring lube or petroleum jelly before installation
• Radium 20-0170 Fuel Surge Tank Bulkhead Fitting, 6AN ORB, 6AN Male Flare to 8.5mm Barb – Radium lists 14-0670 together with its 20-0170 surge tank bulkhead fitting – confirm the barb size you need before ordering

Vehicle Fitment

• Universal – see Application

Not sure if this suits your vehicle? Email sales@coore.com.au and our team will confirm fitment.
