Radium 20-1000-0485 Low Profile Swivel Banjo Fitting, 4AN ORB to 8.5mm Barb

Radium 20-1000-0485 Low Profile Swivel Banjo Fitting, 4AN ORB to 8.5mm Barb

SKU:  20-1000-0485

$59.99
$59.99
5+ In Stock
税込。
Icon 1 Icon 2 Icon 3 Icon 4 Icon 5 Icon 6 Icon 7
詳細を表示する

More info

The Radium Engineering 20-1000-0485 Low Profile Swivel Banjo Fitting has a 4AN ORB inlet and a 8.5mm Barb outlet, giving a 90-degree, low-profile connection.

It rotates a full 360 degrees — even after installation — making it an excellent option for 90-degree connections in tight engine bays where clearance and hose routing are critical. Suitable for high pressure fuel and oil systems (do not exceed 400 psi) and safe for all fuel types, oil and engine coolant.

Key Features

  • 360° swivel — rotates freely even after installation
  • Low profile — 0.797in (20.2mm) installed height
  • High pressure rated — do not exceed 400 psi
  • Media — all fuel types (incl. E85), oil and engine coolant

Specifications

Part Number 20-1000-0485
Inlet 4AN ORB (O-ring boss)
Outlet 8.5mm Barb
Type Low profile 360° swivel banjo
Installed Height 0.797in (20.2mm)
Max Pressure 400 psi
Media All fuels (incl. E85), oil, engine coolant
Sold Individually

Installation Notes

  • Lubricate the ORB O-ring with O-ring lube, petroleum jelly or oil before installation to prevent damage.

Related Swivel Banjo Fittings

See the full range: Radium Swivel Banjo Fittings

Why Radium Engineering?

  • ✔ Designed and manufactured in the USA
  • ✔ CNC machined, precision fit — fuel, oil and coolant safe
  • ✔ Trusted by professional motorsport teams and serious enthusiasts worldwide
  • ✔ Exclusively distributed in Australia by Coore

Genuine Radium Engineering product, supplied by Coore Australia. Sold individually.
