Ecutek "BETA" Software Yaris GR
The Toyota Yaris / Corolla GR tuning suite + Gateway Cable supports the following worldwide vehicles:
Toyota Yaris GR with the 1.6 litre G16E-GTS engine from 2020 to present (Yaris GR RS model with the 1.5 litre M15A-FKS engine is not supported)
Corolla GR with the 1.6 litre G16E-GTS engine, including Circuit and Morizo special editions
FlashFlash is included in this tuning suite, cutting flash times from 20 minutes down to less than 90 seconds.
Flashing a Toyota Yaris / Corolla GR requires 225 Flash Points and the Toyota Yaris/Corolla GR Gateway cable, which is supplied with this suite. Flash Points are available individually or 225 at a time with a Performance Flash Fee.
Following on from our recent GR 86 release we are now releasing our Yaris GR and Corolla GR BETA software to unlock the performance of these great little cars. We know a lot of you have been asking for support for these cars so we are very pleased to be able to provide it.
This is a paid for Beta and is only available to our dealer network. This single software suite will enable you to tune both the Yaris GR and Corolla GR. A wiring loom is required to enable the programming of the car. This will come complete with the tuning suite and will ship out on receipt of your order from the webstore. (Ongoing development will eventually negate the need for this loom and programming will be via OBD.)
Investing in this suite now will ensure you get the planned RaceROM features, PhoneFlash and Retail kit programming for FREE and it will allow you to build your knowledge and base files to get ahead of the market.
More information on the Beta
The Tuning Manual
Map List
We have an ever-developing list of maps that allow you to tune normal, sport, track mode, pedal and torque demand. You can also tune the torque, boost, ignition and fuel targets to deliver the peak performance of your customer's cars. On top of this, you can change the vehicle speed and load limits to allow the engine to deliver higher maximums.
90 sec Fast Flash
Using EcuTek's FastFlash we have managed to significantly reduce flashing times. You'll be pleased to know you can programme either processor in under 90 secs
Example ROM
During dyno testing on the EcuTek development car we managed to increase the power by about 25hp with only simple map changes. These included increases in torque demand limits, load limits and the boost target limits logged below (tuned compared to stock). This illustrates a higher boost target and higher load delivering the power.
The Example ROM is available in ProECU
Custom Logging Parameters
There are a total of 116 parameters added for logging. As you only get 22 parameters on general logging, we have significantly expanded the list to give you the best chance of dialling in the car. Some of these parameters are received in groups but in general, logging speed is around 15-17hz
Part Programmed ECU Recovery
and ROM Dumping
If you end up with a part-programmed ECU, this is recoverable within the software. There is also a ROM dump function to allow you to submit ROMs for support. Obviously, at this point, we will be looking for as many ROM dumps as we can get so that we can expand support.
ECU Connect Support
Standard features such as logging, dashboards and read and clear DTCs will be available at the start of the Beta. As we progress through the beta the expectation is that remote tuning via phoneflash will be added. And as RaceROM features come on stream, custom inputs will be available.
| SKU | ECUT-GR86 |
| Brand | Ecutek |
